| PTFE CSA AWM RATINGS | ||||||
|---|---|---|---|---|---|---|
| CSA TEMP °C(2) | CSA VOLTAGE AC | AVERAGE WALL THICKNESS | INSULATION TYPE | EXTRUDED (EXT) WRAPPED (WRAP) | CONDUCTOR SIZES AWG. | BASIC CONDUCTOR TYPES (Check for Specials) |
| 150 | 150 | .010 | PTFE | EXT | 30-10 | SPC, NPC |
| 200/250 | 300 | .010 | PTFE | EXT | 30-10 | SPC/NPC |
| 200/250 | 600 | .012 | PTFE | EXT | 30-10 | SPC/NPC |
| 200/250 | 1000 | .020 | PTFE | EXT | 28-10 | SPC/NPC |
| 150 | 150 | .010 | PTFE | WRAP | 32-10 | SPC, NPC |
| 200/250 | 300 | .010 | PTFE | WRAP | 32-10 | SPC/NPC |
| 200/250 | 600 | .012 | PTFE | WRAP | 32-10 | SPC/NPC |
| 200/250 | 600 | .030 | PTFE | WRAP | 8-4 | SPC/NPC |
| 200/250 | 1000 | .020 | PTFE | WRAP | 28-10 | SPC/NPC |
| FEP CSA AWM RATINGS | |||||
|---|---|---|---|---|---|
| CSA TEMP °C(2) | CSA VOLTAGE AC | AVERAGE WALL THICKNESS | INSULATION TYPE | CONDUCTOR SIZES AWG. | BASIC CONDUCTOR TYPES (Check for Specials) |
| 150/200 | 150 | .010 | FEP | 28-10 | TPC,(1) SPC, NPC |
| 150/200 | 300 | .010 | FEP | 28-10 | TPC,(1) SPC, NPC |
| 150/200 | 600 | .012 | FEP | 28-10 | TPC,(1) SPC, NPC |
| 150/200 | 600 | .030 | FEP | 8-4 | TPC,(1) SPC, NPC |
(1) TPC single strand size under .0149" reduces temperature to 150°C.
(2) Please consult factory for verification on CSA 150°C, 200°C, and 250°C temperature ratings.
CSA Approval # LL 46216
| PFA CSA AWM RATINGS | |||||
|---|---|---|---|---|---|
| CSA TEMP °C(2) | CSA VOLTAGE AC | AVERAGE WALL THICKNESS | INSULATION TYPE | CONDUCTOR SIZES AWG. | BASIC CONDUCTOR TYPES (Check for Specials) |
| 200/250 | 300 | .010 | PFA | 32-10 | SPC/NPC |
| 200/250 | 600 | .012 | PFA | 32-10 | SPC/NPC |
| 200/250 | 600 | .028 | PFA | 9-2 | SPC/NPC |
| ETFE CSA AWM RATINGS | |||||
|---|---|---|---|---|---|
| CSA TEMP °C(2) | CSA VOLTAGE AC | AVERAGE WALL THICKNESS | INSULATION TYPE | CONDUCTOR SIZES AWG. | BASIC CONDUCTOR TYPES (Check for Specials) |
| 150 | 300 | .010 | ETFE | 32-10 | TPC |
| 150 | 600 | .012 | ETFE | 32-10 | TPC |
| 150 | 600 | .028 | ETFE | 9-2 | TPC |
| 150 | 600 | .040 | ETFE | 1-4/0 | TPC |
| CE and CENELEC | |||||
|---|---|---|---|---|---|
| These approvals state that a product conforms to applicable directives as required by the European economic area. These directives are harmonized under CENELEC, which are based on IEC standards. | |||||
| PTFE Singles | 200°C/250°C | 300V/600V | PTFE Multi-core Cables | 200°C/250°C | 300V/600V |
| FEP Singles | 150°C/200°C | 300V/600V | FEP Multi-core Cables | 150°C/200°C | 300V/600V |
| Thermocouple Wire | 200°C/250°C | 300V | PFA Multi-core Cables | 200°C/250°C | 300V/600V |
| ETFE Singles | 150°C | 600V | |||
